| Specification | Value |
|---|---|
| Active or Passive | Active |
| System Type | Full-Range |
| Configuration | 2-way |
| System Continuous Power | 300 W |
| System Peak Power | 600 W |
| Freq Response (+/-3 dB) | 55 Hz - 20 kHz |
| Bi-amp Mode Switch | No |
| Bluetooth | No |
| IP Certification | None |
| Driver Brand | Wharfedale Pro |
| LF Driver Size | 12" |
| HF Driver Type | Compression Driver |
| HF Diaphragm Material | Titanium |
| HF Exit Size | 1" |
| Preset Library | No |
| Input Connector | Combo Jack: 1/4" - XLR Summed Dual RCA Jacks |
| Waveguide Type | Elliptical |
| Enclosure Material | Polypropylene |
| Grille Material and Finish | Steel Black |
| Finish | Black Polypropylene |
| Handles | 2 |
| Deployment | Flying, Ground, Pole, Wall Mount |
| Pole Mount | 35 mm |
| Brackets Included | No |
| Rigging | Yes |
| M8 | 10 |
| Nominal Coverage (H x V) | 90° x 60° |
| System Rated Impedance | n/a |
| Crossover Frequency | 2.3 kHz |
| Transformer (T) | No |
| Amplifier design | Class D |
| Link Connector | pin XLR |
| Input sensitivity | XLR - 1/4” Combo jack: 0dBu (-2.2dBv or 0.775Vrms) / RCA: 0dBu (-2.2dBv or 0.775Vrms) |
| Max input level | +22 dBu |
| Line output | Switchable LOOP/MIX Balanced socket XLR |
| Main Power | AC100-120 V~/220-240 V~,50/60 Hz |
| Power Supply | High Efficiency Switching Mode Power Supply |
| Included Accessory | User Manual, AC Cable, Dust cover |
| Unpacked - Depth (mm) | 312 |
| Packed - Height (mm) | 408 |
| Packed - Width Front (mm) | 435 |
| Packed - Width Rear (mm) | 435 |
| Packed - Depth (mm) | 663 |
| Weight - Nett (kg) | 12.44 |
| Weight - Gross (kg) | 15.78 |
TITAN-12D
Legendary 12" Bi-amplified full range loudspeaker
Legacy
TITAN-12D
Legendary 12" Bi-amplified full range loudspeaker
12″ Bi-amplified active loudspeaker
300 w Continuous
600 w Peak
Bass Response Optimiser
24-Bit DSP Processing
OVERVIEW
| Name | Type | File |
|---|---|---|
| EASE Library V7.5 | Software | Download |
| TITAN Passive Series Data Sheets | Data Sheets | Download |
| TITAN Passive Series User Manual (Russian) | User Manual | Download |
| TITAN Series User Manual | User Manual | Download |
| TITAN-12D / TITAN-15D User Manual | User Manual | Download |
| TITAN-8 Quick Start Guide | Quick Start Guide | Download |
| TITAN-8A MK II Quick Start Guide | Quick Start Guide | Download |
| TITAN-AX User Manual (German) | User Manual | Download |
| TITAN-X User Manual | User Manual | Download |
| TITAN-X User Manual (German) | User Manual | Download |
| TITAN-Z User Manual | User Manual | Download |
| Wharfedale Pro Preset Library | Software | Download |
| Specification | TITAN-12Z | TITAN-15Z | TITAN-8 | TITAN-X12 | TITAN-X15 | TITAN-12D (legacy) | TITAN-15D (legacy) |
|---|---|---|---|---|---|---|---|
| Catch Line | High power 12" Passive with IP54 Certification | High power 15" Passive with IP54 Certification | Legendary 8" Passive with IP54 Certification | Legendary 12" Passive with IP54 Certification | Legendary 15" Passive with IP54 Certification | Legendary 12" Bi-amplified full range loudspeaker | Legendary 15" Bi-amplified full range loudspeaker |
| Active or Passive | Passive | Passive | Passive | Passive | Passive | Active | Active |
| System Type | Full-Range | Full-Range | Full-Range | Full-Range | Full-Range | Full-Range | Full-Range |
| Configuration | 2-way | 2-way | 2-way | 2-way | 2-way | 2-way | 2-way |
| System Continuous Power | 500 W | 700 W | 150 W | 250 W | 400 W | 300 W | 420 W |
| System Programme Power | 1000 W | 1400 W | 300 W | 500 W | 800 W | ||
| System Peak Power | 2000 W | 2800 W | 600 W | 1000 W | 1600 W | 600 W | 840 W |
| Max SPL @ 1m | 132 dB | 133.5 dB | 124 dB | 128 dB | 129 dB | 133 dB | |
| Freq Response (+/-3 dB) | 55 Hz - 20 kHz | 45 Hz - 20 kHz | 70 Hz - 20 kHz | 55 Hz - 20 kHz | 55 Hz - 20 kHz | 55 Hz - 20 kHz | 50 Hz - 20 kHz |
| Freq Range (-10 dB) | 50 Hz - 20 kHz | 40 Hz - 20 kHz | 65 Hz - 20 kHz | 50 Hz - 20 kHz | 40 Hz - 20 kHz | ||
| IP Certification | IP54 | IP54 | IP54 | IP54 | IP54 | ||
| Driver Brand | Wharfedale Pro | Wharfedale Pro | Wharfedale Pro | Wharfedale Pro | Wharfedale Pro | Wharfedale Pro | Wharfedale Pro |
| LF Driver Size | 12" | 15" | 8" | 12" | 15" | 12" | 15" |
| LF Voice Coil Size | 3" | 4" | 1.53 | 2.5 | 3" | 3" | |
| LF Rated Impedance | 8 Ω | 8 Ω | 8 Ω | 8 Ω | 8 Ω | 4 Ω | |
| LF Power (RE:AES2-2012) | 500 W | 700 W | 150 W | 250 W | 400 W | 400 W | |
| HF Driver Type | Compression Driver | Compression Driver | Compression Driver | Compression Driver | Compression Driver | Compression Driver | Compression Driver |
| HF Voice Coil Size | 1.75" | 2" | 1" | 1.75" | 1.75" | 2" | |
| HF Diaphragm Material | Titanium | Titanium | Mylar | Titanium | Titanium | Titanium | Titanium |
| HF Exit Size | 1" | 1" | 1.2" | 1" | 1" | 1" | 1" |
| HF Power (RE:AES2-2012) | 40 W | 50 W | 20 W | 40 W | 40 W | ||
| HF Rated Impedance | 8 Ω | 8 Ω | 8 Ω | 8 Ω | 8 Ω | 8 Ω | |
| Preset Library | Yes | Yes | Yes | Yes | Yes | ||
| Input Connector | 2 x 4 Pole Speaker Connector | 2 x 4 Pole Speaker Connector | 2 x 4 Pole Speaker Connector / 2 x 6.3mm jacks | 2 x 4 Pole Speaker Connector | 2 x 4 Pole Speaker Connector | Combo Jack: 1/4" - XLR Summed Dual RCA Jacks | Combo Jack: 1/4" - XLR Summed Dual RCA Jacks |
| Waveguide Type | Hybrid Symmetry Horn | Hybrid Symmetry Horn | Elliptical | Hybrid Symmetry Horn | Hybrid Symmetry Horn | Elliptical | Elliptical |
| Enclosure Material | Polypropylene | Polypropylene | Polypropylene | Polypropylene | Polypropylene | Polypropylene | Polypropylene |
| Grille Material and Finish | Steel Black | Steel Black | Steel, Black, Grey, White | Steel Black or White | Steel Black or White | Steel Black | Steel Black |
| Finish | Black Polypropylene | Black Polypropylene | Black, Grey or White Polypropylene | Black or White polypropylene | Black or White Polypropylene | Black Polypropylene | Black Polypropylene |
| Handles | 2 | 2 | 1 | 2 | 2 | 2 | 2 |
| Deployment | Flying, Ground, Pole, Wall Mount | Flying, Ground, Pole, Wall Mount | Flying, Ground, Pole, Wall Mount | Flying, Ground, Pole, Wall Mount | Flying, Ground, Pole, Wall Mount | Flying, Ground, Pole, Wall Mount | Flying, Pole, Wall Mount, Ground |
| Pole Mount | 35 mm | 35 mm | 35 mm | 35 mm | 35 mm | 35 mm | 35 mm With Lock Screw |
| Rigging | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| M6 | 8 | ||||||
| M8 | 10 | 10 | 10 | 10 | 10 | 10 | |
| Nominal Coverage (H x V) | 100° x 80° | 100° x 80° | 90° x 60° | 100° x 80° | 100° x 80° | 90° x 60° | 90° x 60° |
| Amplifier design | Class D | Class D | |||||
| Clip Limiter | NA | NA | |||||
| Link Connector | pin XLR | pin XLR | |||||
| Input sensitivity | XLR - 1/4” Combo jack: 0dBu (-2.2dBv or 0.775Vrms) / RCA: 0dBu (-2.2dBv or 0.775Vrms) | XLR - 1/4” Combo jack: 0dBu (-2.2dBv or 0.775Vrms) RCA: 0dBu (-2.2dBv or 0.775Vrms) | |||||
| Max Input Level | +22 dBu | +22 dBu | |||||
| Line output | Switchable LOOP/MIX Balanced socket XLR | Switchable LOOP/MIX Balanced socket XLR | |||||
| Sensitivity 2.83 V / 1 m | 99 dB | 99 dB | 96 dB | 98 dB | 97 dB | ||
| System Rated Impedance | 8 Ω | 8 Ω | 8 Ω | 8 Ω | 8 Ω | ||
| Crossover Frequency | 2.1 kHz | 2.1 kHz | 2-way 2.4 kHz / Linkwitz-Riley | 2.6 kHz | 2.7 kHz | 2.3 kHz | 1.8 kHz |
| Recommended HPF = BW 18 dB/OCT. | 50 Hz | 40 Hz | 65 Hz | 50 Hz | 40 Hz | ||
| Main Power | AC100-120 V~/220-240 V~,50/60 Hz | AC100-120 V~/220-240 V~,50/60 Hz | |||||
| Power Supply | High Efficiency Switching Mode Power Supply | High Efficiency Switching Mode Power Supply | |||||
| Included Accessory | User Manual, Dust Cover | User Manual, Dust Cover | Quick Start Guide, Dust cover | User Manual, Dust Cover | User Manual, Dust Cover | User Manual, AC Cable, Dust cover | User Manual, AC Cable, Dust cover |
| Unpacked - Height (mm) | 583 | 729 | 396 | 583 | 729 | ||
| Unpacked - Width Front (mm) | 385 | 481 | 266 | 385 | 481 | ||
| Unpacked - Width Rear (mm) | 385 | 481 | 266 | 385 | 481 | ||
| Unpacked - Depth (mm) | 319 | 396 | 221 | 319 | 396 | 312 | 401.8 |
| Packed - Height (mm) | 408 | 840 | 470 | 480 | 830 | 408 | 830 |
| Packed - Width Front (mm) | 435 | 520 | 290 | 320 | 490 | 435 | 500 |
| Packed - Width Rear (mm) | 435 | 520 | 290 | 320 | 490 | 435 | 500 |
| Packed - Depth (mm) | 663 | 500 | 320 | 740 | 510 | 663 | 515 |
| Weight - Nett (kg) | 15.7 | 26.8 | 6.25 | 13.7 | 23.6 | 12.44 | 23.2 |
| Weight - Gross (kg) | 18.8 | 29.3 | 7.36 | 15 | 25.5 | 15.78 | 27.48 |
